Quick Answers
What does FAA AD 2026-14-07 require for Bell 407 operators?
FAA AD 2026-14-07, effective August 21, 2026, requires an initial inspection of the pilot cyclic stick tube assembly on all Bell 407 helicopters with P/N 206-001-342-101 or 206-001-342-101FM installed. Helicopters with 3,600 or more hours time-in-service must then undergo repetitive inspections every 300 hours or 6 months, whichever comes first.
What caused pilot cyclic stick tube cracking on the Bell 407?
The root cause was excessive force applied to the cyclic stick during the standard interior and prestart freedom-of-movement check. This elevated stress at the upper slotted area of the tube. Combined with the design’s high-stress concentration at that location, it caused fatigue cracking — potentially leading to in-flight failure and loss of control.
Quick Compliance Summary
| Regulatory body | Federal Aviation Administration (FAA) |
| AD number | 2026-14-07 — Amendment 39-23408 |
| Docket | FAA-2025-3436 |
| Helicopters affected | All Bell Textron Canada Model 407 with pilot cyclic stick tube assembly P/N 206-001-342-101 or P/N 206-001-342-101FM installed |
| Issue | Fatigue cracking in the pilot cyclic stick tube — root cause identified as excessive force applied during prestart freedom-of-movement checks, aggravated by high-stress concentration at the upper slotted area |
| Required action | Initial inspection of pilot cyclic stick tube assembly. Repetitive inspections every 300 hours TIS or 6 months for tubes with 3,600+ hours TIS. Repair or replacement if cracks are found |
| Compliance deadline | August 21, 2026 |
| US helicopters affected | 972 |
| Source | Federal Register Vol. 91, No. 137, July 17, 2026 — FR Doc 2026-14481 |
Who Should Read This
This update is directly relevant to:
- Directors of Maintenance for Bell 407 operators
- Continuing Airworthiness Managers (CAMs)
- Part 135 helicopter operators
- EMS and air ambulance helicopter operators
- Offshore helicopter operators
- Agricultural and utility helicopter operators
- Flight training organizations using the Bell 407
- Part 145 MRO organizations with Bell 407 capability
The Bell 407 is one of the most widely operated light turbine helicopters in the world. It operates across commercial passenger, EMS, agricultural, offshore, law enforcement, and flight training roles. If your organization operates, maintains, or manages airworthiness for any Bell 407 with the affected cyclic stick tube installed, this AD requires action before August 21, 2026.
At a Glance
| Item | Details |
|---|---|
| AD Number | 2026-14-07 |
| Amendment | 39-23408 |
| Docket | FAA-2025-3436 |
| JASC Code | 6710 — Main Rotor Control |
| Helicopter | Bell 407 (all certificated in any category) |
| Affected part numbers | P/N 206-001-342-101 and P/N 206-001-342-101FM |
| Effective date | August 21, 2026 |
| Initial inspection | All affected helicopters — per Transport Canada AD CF-2024-18 |
| Repetitive inspection | Helicopters with 3,600+ hours TIS — every 300 hours TIS or 6 months, whichever first |
| Unsafe condition | Cracked cyclic stick tube → in-flight failure → loss of control |
| Root cause | Excessive force during prestart freedom-of-movement check |
| Originating authority | Transport Canada AD CF-2024-18, May 29, 2024 |
| US fleet affected | 972 helicopters |
| Interim action | Yes — further rulemaking may follow |
What Changed
The FAA published AD 2026-14-07 on July 17, 2026. It is effective August 21, 2026.
The AD adopts Transport Canada AD CF-2024-18, dated May 29, 2024, as its basis — but goes further than the MCAI in several important ways. The FAA’s version adds inspection requirements not present in the Transport Canada source AD.
The triggering event was a report received by Bell of a fractured pilot cyclic stick tube assembly. The tube fractured at the lower end near the upper slotted area. Follow-up examination of other Bell 407 fleet helicopters found additional tubes with fatigue cracking.
Why It Matters.
The investigation identified the root cause. It was not a material defect or a manufacturing error.
Excessive force applied to the cyclic stick during the freedom-of-movement of the controls and cyclic centering light operation check — part of the standard interior and prestart check procedure — elevated stress at the upper slotted area of the tube. That elevated stress, combined with the slotted area’s high-stress-concentration design feature, caused fatigue cracking over time.
The consequence is direct. An undetected crack in the pilot cyclic stick tube can lead to in-flight failure of the assembly. In-flight failure of the pilot cyclic stick tube results in loss of control of the helicopter.
Loss of control is the most serious failure mode in rotorcraft operations. The fact that the root cause is a routine ground procedure — the prestart check — rather than an in-service failure makes this particularly important. The damage accumulates on the ground before each flight, across hundreds of helicopters.
The FAA’s Additions — Beyond the MCAI
This AD differs from Transport Canada AD CF-2024-18 in three significant ways.
1. Broader applicability
The Transport Canada AD applied only to specific serial number ranges (53000–53900, 53911–53999, 54000–54166, and others). The FAA’s AD applies to all Bell 407 helicopters with the affected cyclic stick tube part numbers installed — regardless of serial number.
2. New repetitive inspection requirement
The FAA added a repetitive inspection requirement for any pilot cyclic stick tube assembly that has accumulated 3,600 or more hours time-in-service. Once that threshold is reached, the tube must be inspected every 300 hours time-in-service or every 6 months, whichever occurs first.
This addition comes from the FAA’s own determination — separate from the MCAI — that a pilot cyclic control stick could experience high loading during hydraulic-off training and other emergency procedure situations. That additional loading, on top of prestart-check fatigue, creates an ongoing risk that the MCAI did not fully address.
3. RFM revision not adopted
Transport Canada AD CF-2024-18 required revising the Bell 407 Rotorcraft Flight Manual Normal Procedures section for certain serial-numbered helicopters to limit the allowable freedom of movement during the prestart check. The FAA did not adopt this provision. The full sweep for freedom of movement is necessary to clear icing and detect jamming or binding during the prestart check. Limiting the sweep would undermine those safety functions.
Who Is Affected — Two Compliance Groups
The AD applies to all Bell 407 helicopters with P/N 206-001-342-101 or P/N 206-001-342-101FM installed. The compliance structure then splits into two groups based on accumulated flight time.
All helicopters:
Perform the initial inspection of the pilot cyclic stick tube assembly per Transport Canada AD CF-2024-18, Part II.
Helicopters with 3,600 or more hours TIS: After completing the initial inspection with no cracks found, perform repetitive detailed inspections every 300 hours TIS or 6 months, whichever occurs first.
The threshold is cumulative time-in-service on the pilot cyclic stick tube assembly — not total airframe time- if the tube has been replaced.
Required Action — Step by Step
Step 1 — Initial inspection:
Inspect the pilot cyclic stick tube assembly for cracks in accordance with Part II of Transport Canada AD CF-2024-18. Note: the FAA replaces the MCAI reference to “Group 2 Helicopters” with “All Helicopters” — the inspection applies regardless of serial number.
Step 2 — On-condition action:
- If no cracks are found: return to service. If the tube has 3,600+ hours TIS, begin the repetitive inspection cycle.
- If cracks are found: repair or replace the pilot cyclic stick tube assembly before further flight per the procedures in Transport Canada AD CF-2024-18.
- If repaired (not replaced): perform repetitive inspections of the repaired tube. Replace within 24 months after the repair.
Step 3 — Repetitive inspections (for tubes with 3,600+ hours TIS):
Inspect every 300 hours TIS or 6 months, whichever occurs first, per Part II, paragraph A of Transport Canada AD CF-2024-18.
Note on time references: Where the Transport Canada AD refers to "air time," the FAA AD uses hours time-in-service. Where the Transport Canada AD refers to its own effective date, use the FAA AD effective date of August 21, 2026.
Operational Impact
972 US-registered Bell 407 helicopters are affected. The FAA estimates 651 of those have or will accumulate 3,600 hours TIS within the 2-year analysis period — meaning the majority of the US Bell 407 fleet will be subject to repetitive inspections.
Initial inspection cost: up to 4 work-hours at $85/hour = $340 per helicopter, parts cost nil.
On-condition repair: 6 work-hours = $510. On-condition replacement: 2 work-hours + $1,544 in parts = $1,714.
For EMS and offshore operators with high-utilization Bell 407 fleets, the 300-hour TIS interval is operationally significant. A helicopter accumulating 300 hours in six months — common in high-cycle commercial operations — will consistently reach the repetitive inspection threshold. Build the inspection into your progressive maintenance schedule now.
The FAA confirmed this AD is an interim action. If a terminating action — such as a redesigned cyclic stick tube — is later developed and approved, further rulemaking may follow.
Key Dates
| Event | Date |
|---|---|
| Transport Canada AD CF-2024-18 issued | May 29, 2024 |
| NPRM published | November 18, 2025 |
| FAA AD 2026-14-07 published | July 17, 2026 |
| AD effective date/compliance deadline | August 21, 2026 |
Source Documents
- Federal Register Vol. 91, No. 137, July 17, 2026 — FR Doc 2026-14481
- Transport Canada AD CF-2024-18, May 29, 2024 — available at tc.canada.ca/en/aviation
- AD Docket: regulations.gov, Docket No. FAA-2025-3436
- FAA contact: Alexis Whitaker — alexis.j.whitaker@faa.gov, (516) 228-7309
FAQ About Bell 407 Pilot Cyclic Stick Tube Cracking
What caused the cyclic stick tube cracking?
The root cause was excessive force applied to the cyclic stick during the freedom-of-movement and cyclic centering light operation check, which is part of the standard interior and prestart check procedure. This elevated stress at the upper slotted area of the tube. Combined with the design’s high-stress concentration at that location, it caused fatigue cracking over time.
Does the AD apply to all Bell 407 serial numbers or only specific ones?
The FAA’s AD applies to all Bell 407 helicopters with P/N 206-001-342-101 or P/N 206-001-342-101FM installed, regardless of serial number. The Transport Canada source AD covered only specific serial number ranges. The FAA broadened the applicability.
What is the repetitive inspection threshold?
3,600 hours time-in-service on the pilot cyclic stick tube assembly. Above that threshold, the tube must be inspected every 300 hours TIS or 6 months, whichever occurs first.
Why did the FAA add the repetitive inspection requirement when the MCAI did not have it?
The FAA determined that the pilot cyclic stick could experience high loading during hydraulic-off training and other emergency procedure situations — loading that the MCAI did not account for. The repetitive inspection addresses this ongoing risk.
Why did the FAA not adopt the RFM revision from the Transport Canada AD?
The Transport Canada AD required limiting the full sweep of the freedom-of-movement check for certain helicopters. The FAA determined this was inappropriate because the full sweep is necessary to clear icing and detect jamming or binding during the prestart check.
If a repaired tube is installed, what are the ongoing obligations?
A repaired tube must be inspected repeatedly and replaced within 24 months of repair—regardless of time-in-service or inspection results. Replacement within 24 months is mandatory.
Is there a reporting requirement?
No. The FAA did not adopt the reporting requirement from the Transport Canada source AD.
